[shortdesc] 48x Gigabit PoE++, 740W PoE Budget, 4x 10G SFP+ Uplinks, DHCP Server, L3 Static Routing, IP20 Steel Chassis, Optimized for Surveillance [/shortdesc]
[properties]
| Model |
AXIS D8248 (02620-004 |
| Product Type |
Managed PoE++ Switch |
| Ports |
48 × RJ45 10/100/1000 Mbps |
| Uplink Ports |
4 × 10G SFP+ |
| PoE Standard |
IEEE 802.3at (30 W on ports 1–40
IEEE 802.3bt (90 W on ports 41–48 |
| PoE Power Budget |
740 W |
| Switching Capacity |
176 Gbps |
| Throughput |
130.944 Mpps |
| MAC Table |
32K |
| Jumbo Frame Support |
10240 bytes |
| Layer Support |
L2 switching + L3 features (IPv4/IPv6 static route, RIP, OSPF |
| Casing |
Steel, Black |
| Power Input |
100–240 V AC, 50/60 Hz |
| Operating Temperature |
0 °C to 45 °C |
| Storage Temperature |
−20 °C to 70 °C |
| Operating Humidity |
0–95% RH (non-condensing |
| Surge Protection |
Network ports: 1 kV; AC lines: 2 kV |
| Dimensions |
Minimum rack depth: 18″ |
| Weight |
5620 g (12.4 lb |
| IP Rating |
IP20 |
| Certifications |
CSA, UL/cUL, CE, VCCI, FCC, RCM, ICES, MIC Telecom |
[/properties]
[specifications]
| Network Protocols |
IPv4, IPv6, HTTP(S, QoS (Layer 3 DiffServ, SMTP, mDNS (Bonjour, UPnP, SNMP v1/v2c/v3, DNS/DNSv6, NTP, TCP/UDP, IGMPv1/v2/v3, ICMP, DHCP, ARP, SSH, CDP, RADIUS, TACACS+, Syslog, IEEE 802.1X, 802.1Q (VLAN, LLDP/LLDP-MED, STP/MSTP/RSTP, LACP |
| Security Features |
IEEE 802.1X, HTTPS encryption, TLS v1.2, X.509, Access Control List (ACL, port security, IP source guard, storm control, private VLAN, DHCP snooping, ARP inspection, password protection, loop protection |
| PoE Pin Assignment |
Ports 1–40: 3/6 (+, 1/2 (−
Ports 41–48: 3/6, 4/5 (+; 1/2, 7/8 (− |
| PoE Output Details |
Ports 1–40: 30 W max (Type 2 Class 4
Ports 41–48: 90 W max (Type 4 Class 8 |
| System Tools |
AXIS Site Designer, AXIS Device Manager, Product selector |
| EMC Standards |
EN 55035, EN 55032 Class A, EN 61000-6-1, EN 61000-6-2, RCM AS/NZS CISPR 32 Class A, ICES(A/NMB(A, VCCI Class A, FCC Part 15 Subpart B Class A |
| Safety Standards |
CAN/CSA C22.2 No. 62368-1 ed. 3, IEC/EN/UL 62368-1 ed. 3, AS/NZS 62368.1, J62368-1 |
| Cybersecurity Support |
AXIS Network Switches Hardening Guide, Axis Vulnerability Management Policy, Security Development Model, SBOM |
[/specifications]
[accesories]
| Included in the Box |
AXIS D8248 Switch, Installation guide, 19″ rack ear kit, Rubber feet (4x, Power cord |
| Optional Accessories |
AXIS TD8901 SFP+ Module LC.LR.X
AXIS TD8902 SFP+ Module LC.SR.X |
[/accesories]
High-Power 48-Port Switching Optimized for Surveillance Networks
The AXIS D8248 Managed PoE++ Switch is a high-performance network solution engineered specifically for demanding security and surveillance deployments. Featuring 48 Gigabit Ethernet ports and a massive 740 W power budget, this switch ensures uninterrupted operation for high-density camera installations. It simplifies network management with an integrated DHCP server for automatic IP assignment and a graphic topology interface that provides an instant visual overview of all connected Axis devices.
Key Benefits & Features
-
High-Power PoE++ (90W: Ports 41–48 support IEEE 802.3bt (up to 90 W, making them ideal for power-hungry devices like PTZ cameras, IR illuminators, and IP speakers. Ports 1–40 support standard 802.3at (30 W.
-
Surveillance Optimized: Designed to complement Axis recorders, the D8248 features "Zero Touch" provisioning tools and an integrated DHCP server for effortless device discovery and setup.
-
High-Speed 10G Uplinks: Equipped with four SFP+ ports, enabling 10 Gigabit fiber connectivity for high-bandwidth backbone connections and future-proof scalability.
-
Advanced L2/L3 Management: Includes comprehensive switching features such as IPv4/IPv6 static routing, OSPF, RIP, VLANs (802.1Q, QoS (DiffServ, and Link Aggregation (LACP.
-
Enhanced Security: Protects your network with IEEE 802.1X access control, HTTPS encryption, ACLs, IP source guard, and DHCP snooping.
Ideal Use Cases
-
Large Scale Surveillance: Perfect for shopping malls, airports, or city surveillance requiring dozens of cameras and sensors on a single switch stack.
-
Mixed Device Ecosystems: Capable of powering a mix of standard dome cameras and high-power PTZ units or Axis audio devices simultaneously.
-
Enterprise Networks: Suitable for core or distribution layers in corporate environments thanks to robust L3 routing and fiber uplinks.
-
Secure Facilities: Meets strict cybersecurity standards with downloadable hardening guides and SBOM availability.
Technical Specifications Snapshot
-
Total PoE Budget: 740 W
-
Port Configuration: 48x 10/100/1000Base-T (RJ45, 4x 10G SFP+ slots
-
Switching Capacity: 176 Gbps
-
Forwarding Rate: 130.944 Mpps
-
Management Interface: Web GUI, CLI (Console, SNMP v1/v2c/v3
-
Dimensions: Rack-mountable (18-inch depth, 1U height
-
Power Supply: Internal, 100-240 V AC
Equip Your Network with the AXIS D8248
Ensure maximum uptime and simplified management for your security infrastructure. Order the AXIS D8248 Managed PoE++ Switch today to build a robust, scalable, and high-power surveillance network.
